LEGGED ROBOT

TALOS

TALOS, the advanced humanoid robot designed to boost your research

TALOS

Your 1.75 meter pal in research

A walking biped robot capable of lifting objects up to 6 kg with one arm fully extended. It is completely configurable, thanks to being fully developed in ROS.

Contact Us

Features

Torque control

TALOS is fully torque-controllable thanks to the torque sensor feedback in all joints, which enables powerful sensing and multi-contact motions.
Contact Us

Features

EtherCAT Network

TALOS’ EtherCAT communication network allows to run control loops at 2 kHz, and up to 5 kHz, which enables TALOS to have highly reactive and dynamic motions.

Features

6kg Payload per arm

TALOS has a payload of 6 Kg with each arm fully extended, as it was designed having in mind the use of heavy industrial tools. This enables our walking biped humanoid robot to effectively perform tasks in various environments such as the Factory of the Future.

Technical

Specifications

SPECS

Height 175 cm
Weight 95 kg
Arm Payload 6 Kg (arm stretched)
Battery autonomy 1,5h (walking) / 3h (stand-by)
Head and Gripper Fully customizable
Torque sensors Full Toque sensors feedback in all joints*
*Except head, wrists and grippers
OS Ubuntu LTS, Real Time OS



OPEN SOURCE

Simulation model available at: http://wiki.ros.org/Robots/TALOS

PREMIUM SOFTWARE

Speed your research with extra software: from Whole-Body Control to navigation, HRI skills or teleoperation.

Download Datasheet

Whole Body Control

A controller written in the ros_control framework developed by PAL Robotics that allows the user to solve a problem consisting of tasks and constraints ordered by priority.

Watch

TALOS in action

TALOS

News

TALOS - locomotion for humanoids in unknown envrionments
Read More

TALOS research: torque-controlled locomotion for humanoids in unknown environments

In recent research the team at PAL Robotics and our French partners, TOWARD and Dynamograde lab, using a new framework,…
The biped humanoid research robot TALOS holding a drill and a wrench
Read More

MEMMO: Giving memories to robots for a better motion generation

Preparing TALOS humanoid for working at Airbus Avoiding obstacles or interacting with a dynamic environment can still be a challenge…
The humanoid robot TALOS at the Humanoids Conference 2020
Read More

The latest in humanoid robots: TALOS, Memmo & Humanoids 2020

Humanoids 2020: the latest news from the conference Last week we participated in The IEEE-RAS International Conference on Humanoid Robots…

Frequently Asked Questions

Get to know how to work closer with TALOS.

TALOS’ Torque control has a low latency of 2kHz.

We provide a state estimation from IMU+kinematics out-of-the-box, a system for fusing this odometry with additional external measurements should be tackled with an additional estimator out of the real-time ros_control loop. This would be safer for the whole body torque control that relies on the CoM estimation.

Via ros_control, you have access to the encoders, IMU, torque sensors at a joint level, Force/Torque sensors on the wrists and ankles and temperature sensors of the robots.

Yes, the URDF includes CoM position, mass and inertia tensors. This model has been extracted from the CAD and it was validated by the full body inverse dynamics and torque control on the walking biped robot.
