Manipulador Móvil
TIAGo Pro
Transforma tu trabajo y lleva tus desarrollos al siguiente nivel con TIAGo Pro: un manipulador móvil de código abierto que combina manipulación, navegación y percepción para impulsar la investigación avanzada y el desarrollo aplicado
Descubre
Manipulación móvil precisa con soporte para una comunicación intuitiva, ideal para espacios de trabajo compartidos y tareas interactivas.
Diseño de hardware accesible y herramientas de percepción integradas; cada aspecto está orientado a favorecer la interacción natural y la investigación avanzada en HRI.
Con una amplia gama de sensores, junto con herramientas de visualización y APIs, TIAGo Pro facilita los procesos de recopilación y análisis de datos.
La arquitectura de software de código abierto permite el desarrollo personalizado, la integración y la experimentación.
Especificaciones Técnicas
| CPU | Intel i5, RAM 16GB, 512 GB SSD |
|---|---|
| VPN Connection | Wireguard |
| Connectivity | Wi-fi 6 (802.11ax, dual band, 2×2) | Bluetooth 5.2 |
| Degrees of Freedom | 2×7 DoF |
|---|---|
| Torque Sensing | On each arm actuator |
| Safety Brakes | 6x at joint level |
| Communication Bus | 1KHz EtherCAT |
| Payload (per arm) | 3 kg (excluding end-effector) |
| Vertical Reach | 92 cm |
| Horizontal Reach | 236 cm |
| End-effector | 2x PAL Parallel Gripper |
| Quick Tool Changer | ✓ |
| Arm Camera Mount | ✓ |
*Single arm version also available
| OS | Ubuntu LTS 64-bits | PREEMPT-RT | ||
|---|---|---|---|
| Middleware | ROS 2 | ||
| Controllers | ros2_controller | Gravity Compensation | ||
| Web Commander | PAL Web GUI | ||
| Included Software Package | |||
| Navigation Stack | ✓ | ||
| Motion Library | ✓ | ||
| Integrations | |||
| MoveIt2 | Nav2 | ros2_control | |
| Development Tools | |||
| Docker Image with PAL SDK | |||
| RViz Plugins | |||
| Compatible Simulators | |||
| MuJoCo | Gazebo | ||
| Degrees of Freedom | 2x DoF (Pan/Tilt) |
|---|---|
| Head Camera | RGB-D Camera |
| Face Screen | 10″ Touchscreen |
| Stereo Speakers | 2x 4W Loudspeakers |
| Microphone | 4-Mic Array |
| LEDs | RGB Lights |
| Degrees of Freedom | 1 DoF |
|---|---|
| Torso Range | 35 cm |
| Safety Brakes | 1x at Joint Level |
| Communication Bus | 1KHz EtherCAT |
| Detachable Laptop Tray | ✓ |
| Expansion Ports | 2x USB 3 | 1x HDMI 2x Ethernet | 1x Power 5A 36V | 1x Power 8A 12V |
| Drive | Omnidirectional (4 DoF) |
|---|---|
| Wheels | 4x Mecanum Wheels |
| LiDAR Sensors | 2x Laser Range Finder 10m | 360º FoV |
| Emergency Stop Button | ✓ |
| CPU | Intel i7, 32 GB RAM, 1 TB SSD | |
|---|---|---|
| GPU | NVIDIA Jetson PC | |
| LiDAR Sensors | 2x Laser Range Finder 25m 360º FoV | |
| Force/Torque Sensors | Wrist 6-axis F/T Sensor | |
| Battery & Charging | ||
| Additional Battery (for increased autonomy) | ||
| Dock Charging Station | ||
| End-Effectors* | ||
| Allegro Hand 16 DoF | ||
| 4x Xela Fingertips Tactile Sensors (only for Allegro Hand) | ||
| RGB-D Camera on Arm Tool Flange | ||
| Premium Software Packages | ||
| Premium Maintenance and Service Plans | ||
Elements not included in default configuration
*Other configurations available
ACCESORIOS
| Degrees of Freedom | 2x 7 DoF |
|---|---|
| Safety Brakes | 6x at joint level |
| Communication Bus | 1KHz EtherCAT (cable) |
| Payload (per arm) | 3 kg |
| Vertical Reach | 96 cm |
| Horizontal Reach | 240 cm |
| Quick Tool Changer | Included |
| Included Software Package | |||
|---|---|---|---|
| Motion Library | |||
| Integrations | |||
| MoveIt 2 | ros2_control | ||
| Development Tool | |||
| Docker Image with PAL API | RViz Integration | ||
| Compatible Simulators | |||
| MuJoCo | Gazebo | ||
| Add-ons | ||
|---|---|---|
| Force/Torque Sensory |
Características
Características
Características
COMPLEMENTOS
